云计算技术-25fa-zb最后一课-MapReduce

云计算技术最后一课的 MapReduce 部分内容整理。

题目

Section 2.3.1: Matrix-Vector Multiplication by MapReduce

2.3.1节：通过 MapReduce 进行矩阵-向量乘法

Suppose we have an $n \times n$ matrix $M$, whose element in row $i$ and column $j$ will be denoted $m_{ij}$. Suppose we also have a vector $v$ of length $n$, whose $j$th element is $v_j$. Then the matrix-vector product is the vector $x$ of length $n$, whose $i$th element $x_i$ is given by $x_i = \sum_{j=1}^{n} m_{ij} \cdot v_j$.

假设我们有一个 $n \times n$ 矩阵 $M$，其第 $i$ 行第 $j$ 列的元素表示为 $m_{ij}$。假设我们还有一个长度为 $n$ 的向量 $v$，其第 $j$ 个元素为 $v_j$。那么矩阵-向量乘积是长度为 $n$ 的向量 $x$，其第 $i$ 个元素 $x_i$ 由 $x_i = \sum_{j=1}^{n} m_{ij} \cdot v_j$ 给出。

• The Map Function

  • for each matrix element $m_{ij}$, produce the key-value pair $(i, m_{ij} \cdot v_j)$
  • 对每个矩阵元素 $m_{ij}$，生成键值对 $(i, m_{ij} \cdot v_j)$

• The Reduce Function

  • sum all the values associated with a given key $i$, and the result is a pair $(i, x_i)$
  • 对与给定键 $i$ 关联的所有值求和，结果是一个对 $(i, x_i)$

Question: Using the matrix-vector multiplication described in Section 2.3.1, applied to the matrix and vector:

使用 2.3.1 节中描述的矩阵-向量乘法，应用于矩阵和向量：

Apply the Map function to this matrix and vector. Then, identify all the key-value pairs that are output of Map.

应用此矩阵和向量的 Map 函数。然后，识别所有 Map 输出的键值对。

Solution:

Each $m_{ij}$ is multiplied by $v_j$, and this product forms the value of a key-value pair that has key $i$, the row number.

每个 $m_{ij}$ 乘以 $v_j$，该乘积形成一个键值对的值，该键值对的键为 $i$，即行号。

Thus, in row-major order, the sixteen key-value pairs produced are:

这样，按行优先顺序，产生的十六个键值对是：

Reduce will sum the values corresponding to the same key, thus, results of reduce are:

$(1,30), (2,70), (3,110), (4,150).$

Reduce 函数将对相同键对应的值进行求和，因此，reduce 的结果是：

$(1,30)，(2,70)，(3,110)，(4,150)。$

Consider a simple example:

举一个简单的例子：

• We have a large dataset where input keys are strings and input values are integers. 我们有一个大型数据集，其中输入键是字符串，输入值是整数。
• We wish to compute the mean of all integers associated with the same key (rounded to the nearest integer). 我们希望计算与同一键关联的所有整数的平均值(四舍五入到最接近的整数)。
• A real-world example might be a large user log from a popular website, where keys represent user ids and values represent some measure of activity such as elapsed time for a particular session. 一个现实的例子可能是来自一个流行网站的大型用户日志，其中键表示用户 ID，值表示某种活动的度量，例如特定会话的经过时间。
• A program Tommy has implemented the problem on MapReduce. He has written a few versions with the pseudo code shown in Figures 1—4. Tommy 实现了 MapReduce 上的问题。他编写了几个版本，伪代码如图 1-4 所示。

Solution 1

a) Initially, Tommy has finished an implementation with Version 1 (Figure 1). He finds that the implementation can have correct results, but the performance is very slow. Why?

最开始，Tommy 完成了版本 1 的实现。他发现该实现可以得到正确的结果，但性能非常慢。为什么？

class MAPPER
  method MAP(string t, integer r)
    EMIT(string t, integer r)

class REDUCER
  method REDUCE(string t, integers [r_1, r_2, ...])
    sum ← 0
    cnt ← 0
    for all integer r ∈ integers [r_1, r_2, ...] do
        sum ← sum + r
        cnt ← cnt + 1
    r_avg ← sum/cnt
    EMIT(string t, integer r_avg)

Figure 1. Computing the Mean: Version 1

It requires shuffling all key-value pairs from mappers to reducers across the network, which is highly inefficient.

它需要通过网络将所有键值对从 mappers 传输到 reducers，这效率非常低下。

Solution 2

b) Tommy wants to improve the performance using combiner. He comes out the second implementation (Version 2 in Figure 2). He finds that he can seldom get the reasonable results. Why?

Tommy 想使用 combiner 来提高性能。他提出了第二个实现。他发现很少能得到合理的结果。为什么？

class MAPPER
  method MAP(string t, integer r)
    EMIT(string t, integer r)

class COMBINER
  method COMBINE(string t, integers [r_1, r_2, ...])
    sum ← 0
    cnt ← 0
    for all integer r ∈ integers [r_1, r_2, ...] do
        sum ← sum + r
        cnt ← cnt + 1
    EMIT(string t, pair (sum, cnt)) // Separate sum and count

class REDUCER
  method REDUCE(string t, pairs [(s_1, c_1), (s_2, c_2) ...])
    sum ← 0
    cnt ← 0
    for all pair (s, c) ∈ pairs [(s_1, c_1), (s_2, c_2) ...] do
        sum ← sum + s
        cnt ← cnt + c
    r_avg ← sum/cnt
    EMIT(string t, integer r_avg)

Figure 2. Computing the Mean: Version 2

• Combiner must have the same input and output key-value type Combiner 必须具有相同的输入和输出键值类型
• Combiners are optimizations that cannot change the correctness of the algorithm. Combiners 是优化，不能改变算法的正确性。
• If Combiner removed, the output value type of the mapper is integer, so the reducer expects to receive a list of integers as values. But the reducer actually expects a list of pairs! 如果移除 Combiner，mapper 的输出值类型是整数，因此 reducer 期望接收一个整数列表作为值。但实际上 reducer 期望的是一对对的列表！
• The correctness of the algorithm is contingent on the combiner running on the output of the mappers, and more specifically, that the combiner is run exactly once. 算法的正确性取决于 combiner 在 mappers 输出上运行，更具体地说，combiner 必须恰好运行一次。

Solution 3

c) After careful design, Tommy finally develops an efficient and correct implementation (Version 3 in Figure 3). Analyze the correctness of the combiner and efficiency of the algorithm (i.e., why it is more efficient than Version 1).

在经过小心谨慎的设计后，Tommy 最终开发出了一个高效且正确的实现。分析 combiner 的正确性和算法的效率(即，为什么它比版本 1 更高效)。

class MAPPER
  method MAP(string t, integer r)
    EMIT(string t, pair (r, 1))

class COMBINER
  method COMBINE(string t, pairs [(s₁, c₁), (s₂, c₂) ...])
    sum ← 0
    cnt ← 0
    for all pair (s, c) ∈ pairs [(s₁, c₁), (s₂, c₂) ...] do
        sum ← sum + s
        cnt ← cnt + c
    EMIT(string t, pair (sum, cnt))

class REDUCER
  method REDUCE(string t, pairs [(s₁, c₁), (s₂, c₂) ...])
    sum ← 0
    cnt ← 0
    for all pair (s, c) ∈ pairs [(s₁, c₁), (s₂, c₂) ...] do
        sum ← sum + s
        cnt ← cnt + c
    r_avg ← sum/cnt
    EMIT(string t, pair (r_avg, cnt))

Figure 3. Computing the Mean: Version 3

• In the mapper we emit as the value a pair consisting of the integer and one—this corresponds to a partial count over one instance. 在 Mapper 中，我们发出一个由整数和一组成的对作为值——这对应于一个实例的部分计数。
• The combiner separately aggregates the partial sums and the partial counts (as before), and emits pairs with updated sums and counts. Combiner 分别聚合部分和与部分计数(如前所述)，并发出具有更新和计数的对。
• The reducer is similar to the combiner, except that the mean is computed at the end. Reducer 类似于 combiner，只是最后计算平均值。
• In essence, this algorithm transforms a non-associative operation (mean of numbers) into an associative operation (element-wise sum of a pair of numbers, with an additional division at the very end). 本质上，该算法将非结合操作(数字的平均值)转换为结合操作(数字对的逐元素求和，最后进行额外的除法)。

Solution 4

d) Tommy analyzes the efficiency of Version 3, and comes out an even more efficient implementation (Version 4 in Figure 4). Why does Version 4 is even more efficient than Version 3?

Tommy 分析了版本 3 的效率，并提出了一个更高效的实现。为什么版本 4 比版本 3 更高效？

class MAPPER
  method INITIALIZE
    S ← new ASSOCIATIVEARRAY
    C ← new ASSOCIATIVEARRAY
  method MAP(string t, integer r)
    S{t} ← S{t} + r
    C{t} ← C{t} + 1
  method CLOSE
    for all term t ∈ S do
      EMIT(term t, pair (S{t}, C{t}))

Figure 4. Computing the Mean: Version 4

• Inside the mapper, the partial sums and counts associated with each string are held in memory across input key-value pairs. 在 mapper 中，与每个字符串关联的部分和与计数在输入键值对之间保存在内存中。
• Intermediate key-value pairs are emitted only after the entire input split has been processed; similar to before, the value is a pair consisting of the sum and count. 仅在处理完整个输入拆分后才发出中间键值对；与之前类似，值是由和与计数组成的一对。

Summary

• Mapper and Reducer is the key operation of divide and conquer. Mapper 和 Reducer 是分而治之的关键操作。
• Combiner is an optimization step to reduce the amount of data transmission Combiner 是减少数据传输量的优化步骤。
• Leverage the design of Mapreduce program. (How to partition the data) 利用 Mapreduce 程序的设计。(如何划分数据)

PS: 内容与 zb 的 PPT 内容一致，仅作整理记录之用。

中文部分由 ChatGPT 翻译，仅供参考，如有错误，欢迎指正。

伪代码部分用 Python 语法高亮，仅作展示之用。
